ABB AX12-30-01-80 3 Poles Contactor, 1SBL911074R8001

4.1 (101 Reviews)

₹1,239.51 (Incl. of all taxes)

₹1,050.43 + ₹189.08 GST

MRP ₹1,569 21% OFF

₹1,239.51 (Incl. of all taxes)

₹1,050.43 + ₹189.08 GST

MRP ₹1,569 21% OFF

About This Product

Key Features

Rated Insulation Volatge: Acc.to IEC 60947-4-1 & VDE 0110 (Gr. C): 690 V.
Rated Impulse Withstand Voltage: 6 KV.
Degree of Protection: Acc.to IEC 60529
IEC 60947-1
EN 60529 Auxiliary Terminals IP20.
Acc.to IEC 60529
IEC 60947-1
EN 60529 Coil Terminals IP20.

Product Specifications

Brand	ABB
Dimensions	4.4x7.4x7.4 cm
Frequency	Auxiliary Circuit: 50 - 60 Hz Main Circuit: 50 - 60 Hz
Item Code	AX12-30-01-80

Product Details

Conventional Free-air Thermal Current (I_th):
acc. to IEC 60947-4-1, Open Contactors q = 40 & 26 A
acc. to IEC 60947-5-1, q = 40 & 16 A
Rated Operational Current AC-1 (I_e):
(690 V) 40 & 25 A
(690 V) 70 & 18 A
(220 / 240 V) 55 & 22 A
Rated Operational Current AC-3 (I_e):
(220 / 230 / 240 V) 55 & 12 A
(380 / 400 V) 55 & 12 A
(415 V) 55 & 12 A
(440 V) 55 & 9 A
(500 V) 55 & 9 A
(690 V) 55 & 7 A
Rated Operational Power AC-3 (P_e):
(220 / 230 / 240 V) 3 kW
(380 / 400 V) 5.5 kW
(415 V) 5.5 kW
(440 V) 4 kW
(500 V) 5.5 kW
(690 V) 5.5 kW
Rated Operational Current AC-15 (I_e):
(220 / 240 V) 4 A
(24 / 127 V) 6 A
(400 / 440 V) 2 A
(500 V) 2 A
(690 V) 2 A
(380 / 440 V) 3 A
Rated Short-time Withstand Current (I_cw):
at 40 & Ambient Temp, in Free Air, from a Cold State 10 s 120 A
at 40 & Ambient Temp, in Free Air, from a Cold State 15 min 26 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 min 55 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 s 280 A
at 40 & Ambient Temp, in Free Air, from a Cold State 30 s 70 A
for 0.1 s 140 A
for 1 s 100 A
Maximum Breaking Capacity:
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 250 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 90 A
Maximum Electrical Switching Frequency:
AC-1 600 cycles per hour
AC-15 1200 cycles per hour
AC-3 1200 cycles per hour
DC-13 900 cycles per hour
Rated Operational Current DC-13 (I_e):
(110 V) 1.1 A / 121 W
(220 V) 0.55 A / 121 W
(400 V) 2.8 A / 134 W
(500 V) 2 A / 144 W
(125 V) 1.1 A / 138 W
(24 V) 6 A / 144 W
(250 V) 0.55 A / 138 W
